SANY STC800T5 STC800E5 80 ton truck crane for sale
main parameter
The total weight of the whole machine is 50000kgMaximum lifting capacity of 80t
The maximum single rope speed of the main winch is 135m/min
Crane arm full lifting/lowering time 65/95s
Other parameters
Maximum lifting height 87.1m
Maximum lifting torque 3528kN · m
Crane arm full extension/retraction time 130/150s
Maximum rotation speed of 1.6r/min
Maximum counterweight 30t
The total length of the machine is 14960mm
The overall width of the machine is 2800mm
The overall height of the machine is 3985mm
Leg span (horizontal x vertical) 8 (5.27) × 6.55m
Engine model Weichai WP12.400E62
The maximum power of the engine is 294/1900kW/rpm
The maximum output torque of the engine is 1920/1000-1400N · m/rpm
Maximum driving speed of 80km/h
Minimum turning radius of 12m
Maximum climbing gradient 42%
Approaching angle ≥ 10 °
Departure angle ≥ 13 °
