Description
XCMG QY50K parameter configuration
Lifting capacity
Maximum rated lifting capacity (t) 50
Minimum working range (m) 3
Maximum rated lifting torque (KN. m) 1000
Maximum lifting capacity (ton) 45-90 tons
Maximum lifting capacity (ton) 45-90 tons
Crane arm size
Crane arm length - Basic arm (m) 10.6
Crane arm length - fully extended arm (m) 33
Crane arm length - basic arm+auxiliary arm (m) 18.75
Length of auxiliary boom (m) 8.15
Homework speed parameter
Crane arm full extension time (s) 75
engine
Chassis engine model SC8DK280Q3/WD615.329
Rated power (kw/rpm) 206/2200 213/2200
Driving parameters
Maximum driving speed (km/h) 75
Minimum turning radius (m) 11
Approach angle/departure angle (°) 16
Minimum ground clearance (mm) 260
Whole machine specifications
Total length of the machine (mm) 12550
Overall width of the machine (mm) 2500
Overall height of the machine (mm) 3380
Leg span
Lifting capacity
Maximum rated lifting capacity (t) 50
Minimum working range (m) 3
Maximum rated lifting torque (KN. m) 1000
Maximum lifting capacity (ton) 45-90 tons
Maximum lifting capacity (ton) 45-90 tons
Crane arm size
Crane arm length - Basic arm (m) 10.6
Crane arm length - fully extended arm (m) 33
Crane arm length - basic arm+auxiliary arm (m) 18.75
Length of auxiliary boom (m) 8.15
Homework speed parameter
Crane arm full extension time (s) 75
engine
Chassis engine model SC8DK280Q3/WD615.329
Rated power (kw/rpm) 206/2200 213/2200
Driving parameters
Maximum driving speed (km/h) 75
Minimum turning radius (m) 11
Approach angle/departure angle (°) 16
Minimum ground clearance (mm) 260
Whole machine specifications
Total length of the machine (mm) 12550
Overall width of the machine (mm) 2500
Overall height of the machine (mm) 3380
Leg span
Vertical x Horizontal (m) 5.14 x 6
